Key Specifications

Standard / Compliance

ICAO Annex 14 Volume 1; L810 (Low Intensity Type B), Medium Intensity Type B (flashing)

Light color

Red

LED lifetime

> 60,000 hours

Optical pattern

2–10° all-direction light emitting type

Flash rate

20–50 fpm (average 30 fpm)

Photometric - Low Intensity Type B

50 cd (steady burning/flashing)

Photometric - Medium Intensity Type B

2000 cd (flashing)

Ingress protection

IP67

Relative humidity

Up to 100%

Operating temperature

-40°C to +70°C

Power source

110/230 V AC, 50/60 Hz or solar panel

Battery (solar version)

12 V / 45 Ah gel type

LED power consumption

12 W / 18 W

Control

Photocell automatic night/day or manual ON/OFF; optional RF remote; optional RF synchronization

Mounting

Pole or ground mounting on 2-inch aluminum pipe

Housing

Aviation yellow powder-coated aluminum

Configuration

Single or dual head

Dimensions (single/double head)

165 mm x 165 mm base (double approx. double footprint)

Net weight (head)

2.5 kg (x2 for dual)

Dimensions (single with solar)

420 mm x 360 mm

Net weight (single with solar)

9.5 kg
